The IRS20124STRPBF is a digital audio driver with discrete dead-time and protection.

Parametrics

IRS20124STRPBF abolute maximum ratings: (1)VB, High side floating supply voltage: -0.3 to 220 V; (2)Vs, High side floating supply voltage: VB-20 to VB+0.3 V; (3)VHO, High side floating output voltage: Vs-0.3 to VB+0.3 V; (4)VCC, Low side fixed supply voltage: -0.3 to 20 V; (5)VLO, Low side output voltage: -0.3 to Vcc+0.3 V; (6)VIN, Input voltage: -0.3 to Vcc+0.3 V; (7)VOC, OC pin input voltage: -0.3 to Vcc+0.3 V; (8)TJ, Junction Temperature: 150℃ max; (9)TS, Storage Temperature: -55 to 150℃; (10)TL, Lead temperature (Soldering, 10 seconds): 300℃ max.

Features

IRS20124STRPBF features: (1)200V high voltage ratings deliver up to 1000W output power in Class D audio amplifier applications; (2)Integrated dead-time generation and bi-directional over current sensing simplify design; (3)Programmable compensated preset dead-time for improved THD performances over temperature; (4)High noise immunity; (5)Shutdown function protects devices from overload conditions; (6)Operates up to 1MHz; (7)3.3V/5V logic compatible input.
