Product Summary

The IRF7456TRPBF is a HEXFET Power MOSFET for high frequency DC-DC converters with synchronous rectification.

Parametrics

IRF7456TRPBF absolute maximum ratings: (1)VDS, Drain-Source Voltage: 20 V max; (2)VGS, Gate-to-Source Voltage: ± 12 V max; (3)ID @ TA = 25℃, Continuous Drain Current, VGS @ 10V: 16A max; (4)ID @ TA = 70℃, Continuous Drain Current, VGS @ 10V: 13 A max; (5)IDM, Pulsed Drain Current: 130A max; (6)PD @TA = 25℃, Maximum Power Dissipation: 2.5 W max; (7)PD @TA = 70℃ Maximum Power Dissipation: 1.6 W max; Linear Derating Factor: 0.02 W/℃ max; (8)TJ , TSTG, Junction and Storage Temperature Range: -55 to + 150 ℃.

Features

IRF7456TRPBF features: (1)Ultra-Low RDS(on) at 4.5V VGS; (2)Low Charge and Low Gate Impedance to Reduce Switching Losses; (3)Fully Characterized Avalanche Voltage and Current.

Diagrams

IRF7456TRPBF Top V iew

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
IRF7456TRPBF
IRF7456TRPBF
International Rectifier
MOSFET MOSFT 20V 16A 6.5mOhm 41nC
Data Sheet
0-1: $1.11
1-25: $0.68
25-100: $0.47
100-250: $0.44
